إيتون أونلاين 9 إي يو بي إس ، 1000 فولت أمبير ، 800 واط ، الإدخال: سي 14 ، الإخراج: (4) سي 13 ، برج
على الانترنت تحويل مزدوج مع كفاءة عالية ، شاشة الكريستال السائل ، فتحة بطاقة الشبكة ، توفالو متوافقة ، منافذ متعددة
| PRODUCT NAME | Eaton 9E UPS |
| CATALOG NUMBER | 9E1000I |
| UPC | 786689166571 |
| PRODUCT LENGTH/DEPTH | 356 mm |
| PRODUCT HEIGHT | 228 mm |
| PRODUCT WIDTH | 144 mm |
| PRODUCT WEIGHT | 22.1 kg |
| WARRANTY | 2 years |
| COMPLIANCES | CE Marked TUV |
| CERTIFICATIONS | IEC/EN 62040-1 IEC/EN 62040-2 CE EAC |
| BATTERY TYPE | Sealed, lead-acid |
| RUNTIME GRAPH | Check the graph above |
| BATTERY REPLACEMENT | Replacable batteries |
| BATTERY QUANTITY | 2 |
| BATTERY MANAGEMENT | Automatic battery test > Deep discharge protection |
| BATTERY RATING | 12 V / 9 Ah |
| EXTENDED BATTERY CAPABILITY | Yes |
| RECEPTACLE | (4) C13 |
| VOLTAGE | 230V |
| WATTAGE | 800 W |
| OUTPUT POWER FACTOR | 0.8 |
| OUTPUT VOLTAGE RANGE | 220/230/240 V +/- 2% |
| OUTPUT WAVEFORM | Sine wave |
| OUTPUT NOMINAL VOLTAGE | 230V default (220/230/240V) |
| VOLTAGE DISTORTION OUTPUT (LINEAR LOAD) - MAX | 3 |
| FEED TYPE | 1 |
| TOPOLOGY | Online/Double-conversion |
| VA RATING | 1000 VA |
| INPUT CONNECTION | C14 |
| INPUT NOMINAL VOLTAGE | 230V default (220/230/240V) |
| NOMINAL FREQUENCY | 50/60 Hz |
| INPUT POWER FACTOR | >.99 |
| INPUT VOLTAGE RANGE | 176-300 V (100 V-300 V with derating) |
| INPUT FREQUENCY RANGE | 40-70 Hz |
| INCLUDES NETWORK CARD | No |
| COMMUNICATION | USB port (HID compliant) Serial port (RS232) Communication slot |
| ETHERNET INTERFACE | No |
| USER INTERFACE | LCD Display |
| POTENTIAL FREE SWITCH CONTACT | No |
| EXPANSION SLOTS | One slot for optional communication card |
| SOFTWARE COMPATIBILITY | Eaton Intelligent Power Manager, Eaton Intelligent Power Protector |
| TYPE OF INTERFACE | Other |
| ALTITUDE | 3000 m |
|---|---|
| NOISE LEVEL | <37 dB at 1 meter |
| TEMPERATURE RANGE | 0° to 40°C (32° to 104°F) |
| RELATIVE HUMIDITY | 0-95% non-condensing |
| CONSTRUCTION TYPE | Free standing model |
|---|---|
| PACKAGE CONTENTS | UPS USB cable Serial cable Quickstart guide Safety instructions |
| PHASE (OUTPUT) | 1 |
| INTERNAL BYPASS | Yes |
| AUTO SHUTDOWN FUNCTION | Yes |
| COLOR | Black |
| EFFICIENCY | 91 |
| RACK MOUNTING KIT | No |
| PHASE (INPUT) | 1 |
| HOT SWAP POWER | No |
